DVP-ES2 Expansion
DVP06XA-E2
Analog I/O Module
- 4 points of analog voltage (10 V, 5 V) / current (20 mA, 0 ~ 20 mA, 4 ~ 20 mA) input *1
- Input resolution: 14-bit (-32,000 ~ +32,000)
- 2 points of analog voltage (-10 V ~ +10 V) / current (0 ~ 20 mA, 4 ~ 20 mA) output
- Output resolution: 14-bit (-32,000 ~ +32,000) / (0 ~ +32,000)
- DVP06XA-E2 mixed analog input/output module receives external 4 points of analog input signals (voltage or current) and converts them into 16-bit digital signals. For the analog signal output, DVP06XA-E2 receives 2 groups of 16-bit digital data coming from the PLC MPU and converts the digital data into 2 points of analog output signals (voltage or current). In addition, you can access the data in the module by applying FROM/TO instructions or reading the average value or writing the output value of channels directly by using MOV instruction.
| Type | Expansion Module | Input/Output | Mix AI/AO | Ethernet | NO |
| Output Type | N.A. | HSC | N.A. | PTO | N.A. |
| Resolution | 14-bit |
