ECU-4784

IEC-61850-3 Certified Power Automation Computers

The ECU-4784 series are TUV IEC 61850-3 and IEEE 1613 certified products, which can provide high reliability and stability for global power automation target market application. With the fanless and robust design, high CPU performance, flexible expansion, rich communication interfaces and intelligent functions, the ECU-4784 series are industrial PC that suitable for smart substation in harsh environment, not the general computers
Product Features and Specifications
Programmable LEDs
Intelligent Connectivity Diagnosis Management
Remote Management
Trusted Platform Module
Virtualization Technology for Directed I/O

Type	Rackmountable Fanless Box PCs	Serial Port	2 x RS-232 (DB9 connectors, Standard) 8 x RS-232/422/485 (Terminal Block) 2,500V isolationn	Ethernet Port	8 x 10/100/1000 Base-T RJ45 ports (Supports teaming function, PXE, LAN1 supports AMT)
Communication Protocol	NA	Mounting	2U Rackmount	Power Supply	Power1: 100 ~ 240 V AC, 100 ~ 240 VDC (default) Power2: 100 ~ 240 V AC, 100 ~ 240 VDC (option)
