EKI-1521

1-port RS-232/422/485 Serial Device Server

It Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy.Provides COM port redirection (Virtual COM), TCP and UDP operation modesSupports up to 921.6 kbps, and any baud rate setting . Allows a max. of 5 hosts to access one serial port.Allows a max. of 16 hosts to be accessed as TCP client mode. Built-in 15 KV ESD protection for all serial signals.Provides rich configuration methods including Windows utility, Telnet console, and Web Browser.Supports 32-bit/64-bit Windows 2000/XP/Vista/7/8/8.1/10, Windows Server2003/2008/2012/2016, and LinuxAutomatic RS-485 data flow control.Supports line to line 2 KV, line to ground 4 KV surge protection

Type	Serial Device Server	Serial Port	1 x RS-232/422/485- 2w/485-4w	Ethernet Port	2 x RJ45
Communication Protocol	ICMP, IP, TCP, UDP,BOOTP, DHCP, Auto IP,SNMP,HTTP, DNS, SMTP, ARP,NTP	Mounting	DIN-rail	Power Supply	12 ~ 48 VDC, redundant dual inputs
