EKI-7712E-4FP

8FE PoE and 4G SFP Managed Ethernet Switch

8 x IEEE 802.3 af/at PoE Fast Ethernet ports + 4 SFP ports
SFP socket for Easy and Flexible Fiber Expansion
Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP (802.1w/1D)
IXM function enables fast deployment
Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS

EKI-7712E-4FP/4FPI supports 8 Fast Ethernet IEEE 802.3 af/at PoE ports and 4 SFP (mini-GBIC) ports. They can provide up to 30 watts per port to fulfill high power consumption PD (Power Device) requirements. They are embedded with Advantech’s IXM function, which can benefit users for fast deployment and can dramatically save engineers time and cost. The EKI-7712E series also supports NMS to help IT managers with networking maintenance and failure prevention. Finally, the EKI-7712E series is equipped with X-Ring Pro which can achieve ultra high speed recovery time of less than 20 ms to ensure network stability. The switch also features a wide -40° to 75°C operating temperature (EKI-7712E-4FPI) and NEMA TS2 rating, making the switch an ideal solution for use in traffic applications. EKI-7712E-4FP/4FPI has successfully passed the EN50121-4 European railway standard requirements for emissions and railway platform and trackside deployment, NEMA TS2 for Traffic Control, EN50121-4 approval for Railway trackside deployment, Dual 48 V DC power input and 1 relay output

Type	PoE Switches	LAN	12 X 10/100BASE-T/TX	Optical Fiber	NA
Connectors	6-pin screw Terminal Block (including relay)	Transmission Distance	NA	Transmission Speed	NA
Standard	NA	LED Indicators	PWR1, PWR2,SYS,Alarm and R.M.	Protocol Support	NA
Switch Properties	NA	Power Supply	48 V DC (46 to 57 VDC), 53 -57 VDC is recommended for 802.3at,redundant dual power input	Certification	EMI : CE, FCC Class A Safety : UL61010-2-201 IEC60950* EMC : EN 61000-4-2
