6th generation Intel® Core™ i7/i5/Celeron processors up to 2.6 GHz with 4GB/8GB DDR4 memory 2 x GbE, 4 x USB 3.0, 2 x RS-232 /422/485, 1 x VGA, 1 x HDMI
Dual power input with alarm output
Compact and fanless design for DIN-rail mount in Control cabinet
Maximum 4 expansion capability on left side for AMAX-54XX series module
Wireless mPCIe module support for 3G/LTE/Wifi/GPS
Advantech's AMAX-5580 is a compact and powerful Control IPC with an Intel Core i7/i5/Celeron CPU. It is the ideal open control platform to be combined with AMAX-5000 SeriesEtherCAT Slice IO modules, and features flexible I/O expansion, real-time I/O control, network capability through various interfaces, and support dual power input for robust powersystem. It also has a built-in standard mini PCI express interface for wireless communication. The AMAX-5580 is the best solution for data gateway, concentrator and data serverapplications, its seamless integration with I/O can save costs and fulfill a diverse range of automation projects, Chassis grounding protection, Independent resource on Intel i210 GbE for better EtherCAT performance, Upstream LAN redundancy (Intel Teaming Function)
