ARS-2620

EN 50155 Intel® i7-6600U/i7-7600U Fanless Railway Box PC

The ARS-2620, a fanless embedded train controller, is certified to EN 50155 standard. With a TX-level operating temperature design, the device endures harsh railway environments from -40°C ~ 85°C*. Furthermore, the railway-specific power design allows multiple voltage inputs: 24V/48V/72V/110V. Featuring with 6 x GbE LAN, 4 with POE function, the ARS-2620 can provide both data connections and electrical power to devices such as IP cameras, fulfilling network video recording application. The features of ARS-2620 can be expanded with its two expansion slots, allowing two isolated modules, such as a COM and a 2.5” SSD SATA drive, and custom modules for best-fit solutions

Cooling	Fanless PC	Processor	Intel® 6th Generation i7-6600U/i7-7600U processor	RAID Support	YES
RAM	SO-DIMM DDR4 1600MHz/1866MHz Up to 16GB	Storage	Supports 2 x 2.5” SSD expansions & RAID 0/1(Optional	Expansion Slot	2 x MiniPCIe & 1 x mSATA for expansion
I/O	2 x RS 232/422/485 1 x USB 2.0 and 2 x USB 3.0	Network	6 x RJ45,10/100/1000 Mbps	Display Port	2 x DVI-D
Max Resolution	1920 x 1080	Mounting	Wall mount	Power Supply	24 V DC
