ITA-5512

EN 50155 Intel® Atom™ E3950 Fanless Compact Controller

ITA-5512 of compact size controller for gateway and event recorder in TCMS application. Collecting subsystem data and providing emergency information to driver machine interface, locomotive operators can improve safety control and optimize decision making based on the collection of data

Cooling	Fanless PC	Processor	Intel® Atom™ E3950	RAID Support	NO
RAM	Technology On board : 8GB DDR3L-1866MHz, Capacity:8GB	Storage	SSD : 1 x 2.5" SSD, eMMC : On-board 32GB eMMC 5.0 interface	Expansion Slot	1 x Mini PCIe and 1 x M.2 B-key support 2242, 3042 with 1 x SIM slot
I/O	USB: 2 x USB 2.0 with A-coded, Serial Port : 1 x DB9, RS-232/422/485 with 2KV Isolation, supports auto-flow control, Display : 1 x DB15, VGA LAN : 2 x LAN with M12 X-coded(F)	Network	2 x M12 X-coded(F), 10/100/1000 Mbps	Display Port	1 x DB15, VGA
Max Resolution	NA	Mounting	NA	Power Supply	110 V DC
