WISE-710

FreeScale i.MX 6 DualLite Industrial Protocol Gateway

The WISE-710 industrial IoT gateway was an open platform with Cortex A9 processor, equipped with 3 x RS-232/485 serial ports, 2 x 10/100/1000 Ethernet ports, and 4 x DI/DO which is great solution to connect your legacy equipments to the new mesh networks. All collected data to the cloud will be secured by key encryption technology from embedded security chip. With its rich I/O, and wide operating temperature design, the gateway plays a role as PLC-side protocol converter, and also data logger for multiple industrial applications, Support data logger on Micro SD card, Operation System: Yocto 2.1/ Ubuntu 16.04, Operation Temperature: -20~55°C

Type	IIOT Gateway	Serial Port	1 x RS-232/485	Ethernet Port	2 x 10/100/1000 Mbps
Communication Protocol	NA	Mounting	Wall, DIN-rail	Power Supply	24 VDC
